1260110 3.7V 10000mAh LiPo Battery
$3.80
Model 1260110 3.7V 10000mAhlithium polymer battery. High energy density with built-in BMS protection. Ideal for electric vehicles and energy storage systems. Custom sizes available. HNF Battery manufacturer.
🔋 1260110 LiPo Battery — 3.7V 10000mAh High Capacity Rechargeable Lithium Polymer Battery
Overview
The 1260110 lithium polymer battery delivers an exceptional 3.7V / 10000mAh (37Wh) in a flat single-cell format measuring 12.0 × 60 × 110mm. As a true large-format LiPo cell, it is purpose-built for power banks, portable energy storage, large-screen tablets, digital signage displays, and industrial portable equipment demanding maximum single-cell runtime. Every unit undergoes 100% capacity verification before shipment — guaranteed to meet rated specifications. CE and UN38.3 certified, in stock for immediate dispatch.
Key Specifications
| Parameter | Specification |
|---|---|
| Model | 1260110 |
| Configuration | 1S1P |
| Nominal Voltage | 3.7V |
| Capacity | 10000mAh |
| Energy | 37Wh |
| Dimensions | 12.0 × 60 × 110 mm |
| Weight | ≈ 210g |
| Charge Voltage | 4.2V |
| Recommended Charge | 0.5C = 5A CC/CV |
| Max Charge Current | 10A (1C) |
| Continuous Discharge | 10A (1C) |
| Peak Discharge | 20A (2C) |
| Discharge Cut-off | 3.0V |
| Self-discharge Rate | ≤ 3% / month |
| Cycle Life | ≥ 500 cycles |
| Capacity Retention | ≥ 80% after 500 cycles |
| Operating Temp | -20°C ~ 60°C |
| Storage Temp | -10°C ~ 45°C |
| Wire Leads | 150mm AWG22 (customizable) |
| Connector | JST-PH 2Pin / XT30 (customizable) |
| Certification | CE / UN38.3 / RoHS |
Large-Format LiPo Comparison
| Model | Voltage | Capacity | Dimensions (mm) | Energy | Best For |
|---|---|---|---|---|---|
| 906090 | 3.7V | 6000mAh | 9.0×60×90 | 22.2Wh | Tablets, monitors |
| 766065 | 3.85V | 5000mAh | 7.6×60×65 | 19.25Wh | HV premium tablets |
| 1057100 | 3.7V | 8000mAh | 10.0×57×100 | 29.6Wh | Large power banks |
| 1260110 ⭐ | 3.7V | 10000mAh | 12.0×60×110 | 37Wh | Power banks, storage |
| 1565130 | 3.7V | 12000mAh | 15.0×65×130 | 44.4Wh | Industrial power packs |
📌 1260110 unique advantage: Highest single-cell capacity in the standard 60mm width family — maximizes energy without moving to multi-cell series configurations or additional BMS complexity.
Features
- ✅ 10000mAh true-rated capacity — 100% capacity verified before shipment, no exaggeration
- ✅ 37Wh high energy — maximum single-cell runtime for power-hungry portable devices
- ✅ 12mm profile — slim enough for integrated power bank and display chassis
- ✅ Integrated PCM protection — overcharge, over-discharge, overcurrent & short-circuit
- ✅ High discharge capability — 10A continuous, 20A peak for multi-device charging loads
- ✅ Low self-discharge ≤3%/month — retains charge during storage & standby
- ✅ Stable flat discharge curve — consistent 3.7V across full 10Ah range
- ✅ ≥500 cycle life / ≥80% retention — 3+ years daily use reliability
- ✅ CE & UN38.3 certified — EU compliant, global air & sea freight ready
- ✅ In stock — standard models dispatched within 3 business days
- ✅ Full OEM/ODM support — custom dimensions, connector, wire harness & branding
Applications
| Industry | Typical Devices |
|---|---|
| 🔋 Portable Power | Power banks, portable energy stations, emergency backup packs |
| 🖥️ Consumer Electronics | Large tablets, 12″+ portable monitors, digital photo frames |
| 🔊 Smart Home & Audio | Large smart speakers, home display hubs, soundbars |
| 🏪 Retail & Payments | Large-screen POS terminals, self-service kiosks |
| 🏥 Medical | Mobile patient carts, portable imaging displays, bedside monitors |
| 🏭 Industrial | Rugged mobile workstations, field data terminals |
| 🔒 Security | Wireless NVR units, large video doorbells, outdoor cameras |
| 💡 Energy Storage | Solar-powered backup lights, off-grid IoT hubs |
Power Bank Application Guide
| Power Bank Output | Compatible Devices | Estimated Charges |
|---|---|---|
| 5V 2A (10W) | Smartphones (~15Wh) | ≈ 2.2 full charges |
| 9V 2A (18W) | Mid-range phones (~17Wh) | ≈ 1.8 full charges |
| 12V 1.5A (18W) | Tablets (~25Wh) | ≈ 1.3 full charges |
| 5V 3A (15W) | TWS + Phone combo | ≈ 3+ device charges |
📌 Estimates based on 37Wh at 85% conversion efficiency. Actual output depends on power bank circuit design.
PCM Protection Details
| Protection | Trigger Threshold | Function |
|---|---|---|
| ⚡ Overcharge | Cutoff at 4.25V | Prevents swelling & thermal runaway |
| 🔋 Over-discharge | Cutoff at 2.75V | Preserves long-term cycle life |
| 🔥 Overcurrent | Trips at >20A | Protects high-current power bank circuits |
| ⚠️ Short-circuit | Instant cutoff | Critical safety for consumer products |
| 🌡️ Thermal range | -20°C ~ 60°C | Reliable across indoor & outdoor use |
Default Package Configuration
| Item | Specification |
|---|---|
| LiPo cell | 1260110 3.7V 10000mAh |
| PCM protection board | ✅ Included |
| Capacity verification | ✅ 100% tested before shipment |
| Wire leads | 150mm AWG22 red & black |
| Connector | JST-PH 2Pin (XT30 optional) |
| Label | Standard / OEM white-label available |
| Stock status | ✅ In stock — ships within 3 business days |
Shipping & Compliance Note
| Parameter | Detail |
|---|---|
| Energy content | 37Wh |
| IATA air freight threshold | 160Wh (Section II) |
| Air freight eligible | ✅ Yes — below 160Wh limit |
| UN38.3 certified | ✅ — DG documentation included |
| Packaging | Per IATA PI 965 Section II requirements |
✈️ At 37Wh, this battery qualifies for air freight as Section II lithium battery — significantly easier and cheaper than batteries over 100Wh.
OEM / Custom Options
| Option | Details |
|---|---|
| Voltage | 3.7V / 3.85V HV / 7.4V (2S) / 11.1V (3S) |
| Capacity | 6000mAh – 20,000mAh |
| Dimensions | Custom length / width to your drawing |
| Wire length & gauge | 100mm ~ 300mm / AWG18 ~ AWG24 |
| Connector | JST-PH / XT30 / XT60 / Anderson / bare wire |
| Protection | Standard PCM / Smart BMS / Fuel gauge IC |
| Certification | CE, UN38.3, RoHS, UL, IEC 62133 on request |
| Branding | OEM / white-label labeling & retail packaging |
| MOQ | 30 pcs |
Certification & Compliance
| Certificate | Scope | Status |
|---|---|---|
| ✅ CE | EU market compliance | Standard |
| ✅ UN38.3 | Global air & sea freight | Standard |
| ✅ RoHS | Hazardous substance compliance | Standard |
| ✅ MSDS | Material safety data sheet | Standard |
| 📋 UL 2054 | US household battery standard | On request |
| 📋 IEC 62133 | Portable battery safety | On request |
| 📋 KC | Korea market | On request |
| 📋 BIS | India market | On request |
Why Choose Us?
- 🏭 Factory Direct — own production lines, zero intermediaries, best pricing
- 🔋 True-rated capacity — every 1260110 unit 100% capacity tested before shipment
- 📐 Large-format LiPo specialist — 10Ah+ single-cell engineering expertise
- ✈️ Air freight friendly — 37Wh well within IATA Section II limit
- 📋 CE + UN38.3 ready — full DG documentation for procurement compliance
- 🔬 7-day OEM sample — rapid custom large-cell prototyping
- 🚢 DG logistics expertise — large LiPo pack shipping via air, sea & express courier
- 🛠️ Full OEM service — enclosure-fit engineering to certified mass production
📩 Need a high-capacity single-cell solution? Send us your enclosure dimensions and power requirements — custom quote within 24 hours.
