6567102 14.8V 4000mAh LiPo Battery
$21.80
6567102 14.8V 4000mAh LiPo battery for FPV drones, with 240A peak discharge and 8mΩ impedance for competition RC vehicles and racing drones.
The HNF-6567102 is a high-performance 14.8V (4S) lithium polymer battery pack delivering 4000mAh with an exceptional 240A peak discharge capability. With 59.2Wh of total energy and ultra-low 8mΩ impedance, this is a purpose-built power source for high-performance applications — competition-grade RC vehicles, FPV racing drones, high-power portable jump starters, and heavy-duty power tool conversions that demand extreme current delivery and sustained high-voltage output.
Model number: HNF-6567102 4000mAh 14.8V
Nominal voltage: 14.8 V
Nominal capacity: 4000 mAh
Dimension: 65 x 67 x 102 mm
Cell configuration: 4S1P
Certification: CE / RoHS / IEC62133 / UN38.3 / MSDS
Warranty: 12 months
Specifications
| Item | Rating | Remark |
|---|---|---|
| Model | HNF-6567102 4000mAh 14.8V | |
| Nominal Capacity | 4000 mAh | Standard discharge (0.2C5A) after standard charge |
| Nominal Voltage | 14.8 V | |
| Dimension | 65 x 67 x 102 mm | |
| Weight | Approx: 380 g | |
| Cut-off Charge Voltage | 16.8 V | |
| Cut-off Discharge Voltage | 12.0 V | |
| Initial Impedance | ≤ 8 mΩ | |
| Standard Charge | 0.2C CC charge to CV then CV till current ≤0.01C | Charge time: approx. 7.0 h |
| Max. Constant Charging Current | 240 A (high-rate) | |
| Standard Discharge | Discharge at 0.2C5A to cut-off voltage | |
| Max. Continuous Discharging Current | 240 A (high-rate) | |
| Cycle Life | ≥500 cycles, 80% capacity retention | |
| Operating Temperature | Charge 0~+45℃ / Discharge -20~+60℃ | |
| Storage Temperature | -10~+45℃ | |
| Storage Humidity | 45-75% RH |
Application Field
Competition-grade RC cars and trucks, FPV racing drones and freestyle quads, high-power portable jump starters, heavy-duty power tool battery conversions, high-end hobby-grade robotics.
Main Advantages
- High energy density, stable 14.8V nominal voltage
- High-drain capable, stable discharge performance
- Lightweight and ultra-thin; dimensions customizable on request
- Extremely safe, low self-discharge, long cycle life (≥500 cycles, 80% capacity retention)
- Reliable PCM protection against over-charge and over-discharge
- Wide operating temperature: -20℃ ~ +60℃
FAQ
Q: Do you accept customization?
A: Yes. We are a professional custom lithium battery manufacturer. Share your required voltage, capacity, and dimensions.
Q: Can this be shipped by air?
A: 59.2 Wh — well within the 100Wh limit, suitable for air freight with MSDS & UN38.3 documentation.
Q: Do you offer samples?
A: Samples are available; sample cost is refunded once a bulk order is confirmed.
Q: What is the MOQ?
A: In-stock items have no MOQ. For customized cells, MOQ is typically 3,000-10,000 pcs depending on size and capacity.
Q: How is quality assured?
A: Multi-stage quality control across R&D, incoming inspection, production, pre-shipment, and after-sales, fully certified with CE, RoHS, and IEC62133.
