906090 3.7V 6000mAh LiPo Battery: The High-Rate 9mm 22.2Wh Cell for Tablets, Power Banks & Smart Displays
The 906090 3.7V 6000mAh LiPo battery is a high-rate 9mm-thin 60x90mm lithium polymer cell with 6A/12A discharge and 22.2Wh for tablets, power banks, and smart displays. Specs, applications & OEM options.
For devices that need flagship capacity and real power output but still have to stay slim, the 906090 3.7V 6000mAh LiPo battery is the high-rate option in the 60 × 90mm family. It delivers 6000mAh (22.2Wh) at 3.7V with a 6A continuous / 12A peak discharge rating — and at just 9mm thick it still slips behind a large tablet, portable monitor, or premium power bank without breaking the enclosure budget.
This guide covers the HNF-906090 cell’s specification, its high-rate architecture, and where that extra current and capacity earn their keep.
Why the 906090 Format: 6000mAh + 6A High Rate in 9mm
The model number encodes the geometry. The 906090 LiPo measures:
- 90 = 9.0mm thickness
- 60 = 60mm width
- 90 = 90mm length
- 6000 = 6000mAh capacity
The result is a 1S1P lithium polymer battery with a footprint of 9.0 × 60 × 90 mm and a weight of approximately 115g. The extra 3mm versus the 6mm 606090 cell is the trade-off for pushing capacity to 6000mAh and supporting a 6A/12A high-rate discharge — ideal when a device drives a bright backlight, an audio amplifier, or a motor load.
HNF-906090 3.7V 6000mAh: Complete Specifications
The HNF-906090 is a 1S1P high-rate lithium polymer cell with a PCM (Protection Circuit Module). Full ratings:
- Model: HNF-906090 6000mAh 3.7V
- Nominal capacity: 6000 mAh (standard discharge 0.2C after standard charge)
- Nominal voltage: 3.7 V
- Dimensions: 9.0 × 60 × 90 mm
- Weight: Approx. 115 g
- Configuration: 1S1P
- Energy: 22.2 Wh
- Cut-off charge voltage: 4.2 V
- Cut-off discharge voltage: 3.0 V
- Max. constant charging current: 3000 mA (0.5C)
- Max. continuous discharge current: 6000 mA (1.0C)
- Peak discharge current: 12A (short bursts)
- Standard charge: 0.2C CC-CV, approx. 7.0 h
- Cycle life: ≥ 500 cycles at 80% capacity retention
- Operating temperature: Charge 0~+45°C / Discharge -20~+60°C
- Storage temperature: -10~+25°C (≤12 months)
- Certifications: CE / RoHS / IEC62133 / UN38.3 / MSDS
- Warranty: 12 months
Key Advantages of the 906090 High-Rate LiPo Cell
- Flagship 6000mAh capacity — the highest-capacity cell in the 60×90mm family for all-day runtime.
- High-rate 6A / 12A output — drives backlights, audio amps, and motors that a standard cell cannot.
- Slim 9mm profile — still fits behind large displays and panels without exceeding enclosures.
- 22.2Wh in a flat footprint — high energy density at a stable 3.7V.
- Safe and long-lived — PCM protection plus ≥500 cycles at 80% retention.
- Wide temperature range — discharges reliably from -20°C to +60°C.
- Customizable — HNF manufactures pouch cells to customer-specified dimensions and capacities.
Where the 906090 3.7V LiPo Is Used
The 9mm/6000mAh/high-rate combination targets devices that draw sustained or burst current from a large, flat cell:
1. Large Tablets & Portable Monitors
Big screens and bright backlights need both capacity and current. The 906090’s 6A continuous rating keeps a large tablet or portable monitor running all day without voltage sag.
2. Premium Smart Speakers & Home Audio
Battery-powered smart speakers and audio systems pull steady current through Class-D amplifiers. The high-rate cell delivers clean power and long playback between charges.
3. Premium Power Banks & Backup Power
High-capacity power banks need cells that can both store energy and discharge it quickly. 22.2Wh and a 12A peak make the 906090 a strong building block.
4. POS Terminals & Self-Service Kiosks
Large-screen POS and kiosks run touch panels, printers, and scanners from a hidden flat cell. The 906090 handles the mixed load profile.
5. Portable Patient Monitors & Rugged Tablets
Medical displays and rugged mobile workstations demand reliable, certified power. The cell’s CE/RoHS/IEC62133 compliance and stable high-current discharge suit clinical and field use.
Safety, Certification & Shipping
At 22.2Wh the HNF-906090 is well below the 100Wh air-freight limit, so it ships by air with standard MSDS and UN38.3 documentation — no dangerous-goods handling required. Every cell is built to CE, RoHS, and IEC62133 standards and protected by an onboard PCM against over-charge, over-discharge, and short circuit. HNF applies multi-stage quality control across R&D, incoming inspection, production, pre-shipment, and after-sales.
Customization & OEM Options
The 906090 is a standard catalog cell, but HNF Battery is a custom lithium battery manufacturer. Share your required voltage, capacity, and dimensions and the engineering team will propose a pouch cell, protection circuit, and connector configuration to match — including higher-rate PCM tuning if your application needs it. In-stock items ship with no MOQ; custom cells typically start at 3,000–10,000 pcs depending on size and capacity. Samples are available and the sample cost is refunded once a bulk order is confirmed.
Frequently Asked Questions
Q: Can the 906090 be shipped by air?
A: Yes. At 22.2Wh it is well within the 100Wh limit and ships with MSDS & UN38.3 documentation.
Q: How much current can it deliver?
A: 6A continuous (1.0C) and up to 12A peak for short bursts — far more than a standard thin LiPo.
Q: What is the minimum order quantity?
A: In-stock cells have no MOQ. Custom pouch cells typically start at 3,000–10,000 pcs.
Q: Can you customize the size?
A: Yes — HNF manufactures LiPo cells to customer-specified dimensions and capacities.
Q: Is the cell protected?
A: Yes, every HNF-906090 includes a PCM for over-charge, over-discharge, and short-circuit protection.
